Конфиги Conky

[code=php]
background yes
update_interval 1

cpu_avg_samples 2
net_avg_samples 2
temperature_unit celsius

double_buffer yes
no_buffers yes
text_buffer_size 2048

gap_x 10
gap_y 30
minimum_size 190 450
maximum_width 190

own_window_class conky
own_window yes
own_window_type conky
own_window_transparent yes
own_window_hints undecorated,below,sticky,skip_taskbar,skip_pager

border_inner_margin 0
border_outer_margin 0
alignment tr

draw_shades no
draw_outline no
draw_borders no
draw_graph_borders no

override_utf8_locale yes
use_xft yes
xftfont caviar dreams:size=8
xftalpha 0.5
uppercase no

default_color FFFFFF
color1 DDDDDD
color2 AAAAAA
color3 888888
color4 F0292C

lua_load ~/.conky/conky_red.lua
lua_draw_hook_post main

#${voffset 35}
#${goto 95}${color3}${font ubuntu:size=32}${time %e}${color1}${voffset 0}${offset -60}${font ubuntu:size=10}${time %A}
#${goto 85}${color2}${voffset -2}${font ubuntu:size=9}${time %b}${voffset -2} ${color}${font ubuntu:size=12}${time %Y}${font}
#
#${voffset 70}


TEXT
${voffset 35}
${goto 95}${color4}${font ubuntu:size=22}${time %e}${color1}${offset -50}${font ubuntu:size=10}${time %A}
${goto 85}${color2}${voffset -2}${font ubuntu:size=9}${time %b}${voffset -2} ${color3}${font ubuntu:size=12}${time %Y}${font}

${voffset 80}
${goto 90}${font Ubuntu:size=7,weight:bold}${color}CPU
${goto 90}${font Ubuntu:size=7,weight:normal}${color1}${top name 1}${alignr}${top cpu 1}%
${goto 90}${font Ubuntu:size=7,weight:normal}${color2}${top name 2}${alignr}${top cpu 2}%
${goto 90}${font Ubuntu:size=7,weight:normal}${color3}${top name 3}${alignr}${top cpu 3}%
${goto 90}${cpugraph 10,100 666666 666666}
${goto 90}${voffset -10}${font Ubuntu:size=7,weight:normal}${color}${threads} process

${voffset 20}
${goto 90}${font Ubuntu:size=7,weight:bold}${color}MEM
${goto 90}${font Ubuntu:size=7,weight:normal}${color1}${top_mem name 1}${alignr}${top_mem mem 1}%
${goto 90}${font Ubuntu:size=7,weight:normal}${color2}${top_mem name 2}${alignr}${top_mem mem 2}%
${goto 90}${font Ubuntu:size=7,weight:normal}${color3}${top_mem name 3}${alignr}${top_mem mem 3}%

${voffset 15}
${goto 90}${font Ubuntu:size=7,weight:bold}${color}DISKS

${goto 90}${diskiograph 30,100 666666 666666}${voffset -30}
${goto 90}${font Ubuntu:size=7,weight:normal}${color}used: ${swapperc} /swap
${goto 90}${font Ubuntu:size=7,weight:normal}${color}used: ${fs_used /home} /home


${voffset 10}
${image /home/electrichp/.conky/megafon-new.png -p 0,483 -s 30x30}${tab 32}${font Ubuntu:size=16,weight:bold}${color3}МЕГАФОН-3G${alignr}${color2}${font Ubuntu:size=10,weight:bold}${color1}
${tab 31}${if_up ppp0} Мой ip: ${addr ppp0} ${endif}${if_up wlan0}wifi ${addr wlan0}${endif}
${font Ubuntu:size=7,weight:bold}${color1}${tab 15}Выгрузка:\
${tab 57}Загрузка:
${upspeedgraph ppp0 30, 70 888888 DDDDDD}\
${tab 50}${downspeedgraph ppp0 30, 70 888888 DDDDDD}
${tab 15}${upspeedf ppp0} Кб/с\
${tab 57}${downspeedf ppp0} Кб/с

${font Ubuntu:size=8,weight:bold}${color1}Всего отдано: ${font Ubuntu:size=10,weight:bold}${color4} ${totalup ppp0}
${font Ubuntu:size=8,weight:bold}${color1}Всего загружено: ${font Ubuntu:size=10,weight:bold}${color4}${totaldown ppp0}
${font Ubuntu:size=7,weight:bold}${color}открытые порты: ${alignr}${color2}${tcp_portmon 1 65535 count} :
${font Ubuntu:size=7,weight:bold}${color}${offset 27}IP${alignr}DPORT
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 0}${alignr 1}${tcp_portmon 1 65535 rport 0}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 1}${alignr 1}${tcp_portmon 1 65535 rport 1}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 2}${alignr 1}${tcp_portmon 1 65535 rport 2}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 3}${alignr 1}${tcp_portmon 1 65535 rport 3}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 4}${alignr 1}${tcp_portmon 1 65535 rport 4}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 5}${alignr 1}${tcp_portmon 1 65535 rport 5}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 6}${alignr 1}${tcp_portmon 1 65535 rport 6}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 7}${alignr 1}${tcp_portmon 1 65535 rport 7}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 8}${alignr 1}${tcp_portmon 1 65535 rport 8}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 9}${alignr 1}${tcp_portmon 1 65535 rport 9}
${font Ubuntu:size=7,weight:normal}${color1}${tcp_portmon 1 65535 rip 10}${alignr 1}${tcp_portmon 1 65535 rport 10}
[/code]

[code=php]
require 'cairo'

--------------------------------------------------------------------------------
-- clock DATA
-- HOURS
clock_h = {
{
name='time', arg='%H', max_value=12,
x=110, y=80,
graph_radius=53,
graph_thickness=3,
graph_unit_angle=30, graph_unit_thickness=30,
graph_bg_colour=0xffffff, graph_bg_alpha=0.0,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.3,
txt_radius=34,
txt_weight=1, txt_size=10.0,
txt_fg_colour=0xFFFFFF, txt_fg_alpha=0.6,
graduation_radius=53,
graduation_thickness=6, graduation_mark_thickness=2,
graduation_unit_angle=30,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.3,
},
}
-- MINUTES
clock_m = {
{
name='time', arg='%M', max_value=60,
x=110, y=80,
graph_radius=57,
graph_thickness=2,
graph_unit_angle=6, graph_unit_thickness=6,
graph_bg_colour=0xffffff, graph_bg_alpha=0.1,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.3,
txt_radius=70,
txt_weight=0, txt_size=9.0,
txt_fg_colour=0xFFFFFF, txt_fg_alpha=0.6,
graduation_radius=57,
graduation_thickness=0, graduation_mark_thickness=2,
graduation_unit_angle=30,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.3,
},
}
-- SECONDS
clock_s = {
{
name='time', arg='%S', max_value=60,
x=110, y=80,
graph_radius=50,
graph_thickness=2,
graph_unit_angle=6, graph_unit_thickness=2,
graph_bg_colour=0xffffff, graph_bg_alpha=0.0,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.2,
txt_radius=40,
txt_weight=0, txt_size=12.0,
txt_fg_colour=0xFFFFFF, txt_fg_alpha=0.3,
graduation_radius=0,
graduation_thickness=0, graduation_mark_thickness=0,
graduation_unit_angle=0,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.0,
},
}

--------------------------------------------------------------------------------
-- gauge DATA
gauge = {
{
name='cpu', arg='cpu0', max_value=100,
x=85, y=200,
graph_radius=24,
graph_thickness=5,
graph_start_angle=180,
graph_unit_angle=2.7, graph_unit_thickness=2.7,
graph_bg_colour=0xffffff, graph_bg_alpha=0.1,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.2,
hand_fg_colour=0xF0292C, hand_fg_alpha=1.0,
txt_radius=34,
txt_weight=0, txt_size=8.0,
txt_fg_colour=0xF0292C, txt_fg_alpha=1.0,
graduation_radius=28,
graduation_thickness=0, graduation_mark_thickness=1,
graduation_unit_angle=27,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.3,
caption='',
caption_weight=1, caption_size=8.0,
caption_fg_colour=0xFFFFFF, caption_fg_alpha=0.3,
},

{
name='memperc', arg='', max_value=100,
x=85, y=300,
graph_radius=24,
graph_thickness=5,
graph_start_angle=180,
graph_unit_angle=2.7, graph_unit_thickness=2.7,
graph_bg_colour=0xffffff, graph_bg_alpha=0.1,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.2,
hand_fg_colour=0xF0292C, hand_fg_alpha=1.0,
txt_radius=10,
txt_weight=0, txt_size=8.0,
txt_fg_colour=0xF0292C, txt_fg_alpha=1.0,
graduation_radius=23,
graduation_thickness=0, graduation_mark_thickness=2,
graduation_unit_angle=27,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.5,
caption='',
caption_weight=1, caption_size=8.0,
caption_fg_colour=0xFFFFFF, caption_fg_alpha=0.3,
},
{
name='fs_used_perc', arg='/home', max_value=100,
x=85, y=380,
graph_radius=24,
graph_thickness=5,
graph_start_angle=180,
graph_unit_angle=2.7, graph_unit_thickness=2.7,
graph_bg_colour=0xffffff, graph_bg_alpha=0.1,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.2,
hand_fg_colour=0xF0292C, hand_fg_alpha=1.0,
txt_radius=34,
txt_weight=0, txt_size=8.0,
txt_fg_colour=0xF0292C, txt_fg_alpha=1.0,
graduation_radius=28,
graduation_thickness=0, graduation_mark_thickness=1,
graduation_unit_angle=27,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.3,
caption='/home',
caption_weight=1, caption_size=8.0,
caption_fg_colour=0xFFFFFF, caption_fg_alpha=0.5,
},
{
name='swapperc', arg='', max_value=100,
x=85, y=380,
graph_radius=18,
graph_thickness=5,
graph_start_angle=180,
graph_unit_angle=2.7, graph_unit_thickness=2.7,
graph_bg_colour=0xffffff, graph_bg_alpha=0.1,
graph_fg_colour=0xFFFFFF, graph_fg_alpha=0.2,
hand_fg_colour=0xF0292C, hand_fg_alpha=1.0,
txt_radius=10,
txt_weight=0, txt_size=8.0,
txt_fg_colour=0xF0292C, txt_fg_alpha=1.0,
graduation_radius=28,
graduation_thickness=0, graduation_mark_thickness=1,
graduation_unit_angle=27,
graduation_fg_colour=0xFFFFFF, graduation_fg_alpha=0.3,
caption='/swap',
caption_weight=1, caption_size=8.0,
caption_fg_colour=0xFFFFFF, caption_fg_alpha=0.5,
},
}

-------------------------------------------------------------------------------
-- rgb_to_r_g_b
-- converts color in hexa to decimal
--
function rgb_to_r_g_b(colour, alpha)
return ((colour / 0x10000) % 0x100) / 255., ((colour / 0x100) % 0x100) / 255., (colour % 0x100) / 255., alpha
end

-------------------------------------------------------------------------------
-- angle_to_position
-- convert degree to rad and rotate (0 degree is top/north)
--
function angle_to_position(start_angle, current_angle)
local pos = current_angle + start_angle
return ( ( pos * (2 * math.pi / 360) ) - (math.pi / 2) )
end

-------------------------------------------------------------------------------
-- draw_clock_ring
-- displays clock
--
function draw_clock_ring(display, data, value)
local max_value = data['max_value']
local x, y = data['x'], data['y']
local graph_radius = data['graph_radius']
local graph_thickness, graph_unit_thickness = data['graph_thickness'], data['graph_unit_thickness']
local graph_unit_angle = data['graph_unit_angle']
local graph_bg_colour, graph_bg_alpha = data['graph_bg_colour'], data['graph_bg_alpha']
local graph_fg_colour, graph_fg_alpha = data['graph_fg_colour'], data['graph_fg_alpha']

-- background ring
cairo_arc(display, x, y, graph_radius, 0, 2 * math.pi)
cairo_set_source_rgba(display, rgb_to_r_g_b(graph_bg_colour, graph_bg_alpha))
cairo_set_line_width(display, graph_thickness)
cairo_stroke(display)

-- arc of value
local val = (value % max_value)
local i = 1
while i <= val do
cairo_arc(display, x, y, graph_radius,( ((graph_unit_angle * i) - graph_unit_thickness)*(2*math.pi/360) )-(math.pi/2),((graph_unit_angle * i) * (2*math.pi/360))-(math.pi/2))
cairo_set_source_rgba(display,rgb_to_r_g_b(graph_fg_colour,graph_fg_alpha))
cairo_stroke(display)
i = i + 1
end
local angle = (graph_unit_angle * i) - graph_unit_thickness

-- graduations marks
local graduation_radius = data['graduation_radius']
local graduation_thickness, graduation_mark_thickness = data['graduation_thickness'], data['graduation_mark_thickness']
local graduation_unit_angle = data['graduation_unit_angle']
local graduation_fg_colour, graduation_fg_alpha = data['graduation_fg_colour'], data['graduation_fg_alpha']
if graduation_radius > 0 and graduation_thickness > 0 and graduation_unit_angle > 0 then
local nb_graduation = 360 / graduation_unit_angle
local i = 1
while i <= nb_graduation do
cairo_set_line_width(display, graduation_thickness)
cairo_arc(display, x, y, graduation_radius, (((graduation_unit_angle * i)-(graduation_mark_thickness/2))*(2*math.pi/360))-(math.pi/2),(((graduation_unit_angle * i)+(graduation_mark_thickness/2))*(2*math.pi/360))-(math.pi/2))
cairo_set_source_rgba(display,rgb_to_r_g_b(graduation_fg_colour,graduation_fg_alpha))
cairo_stroke(display)
cairo_set_line_width(display, graph_thickness)
i = i + 1
end
end

-- text
local txt_radius = data['txt_radius']
local txt_weight, txt_size = data['txt_weight'], data['txt_size']
local txt_fg_colour, txt_fg_alpha = data['txt_fg_colour'], data['txt_fg_alpha']
local movex = txt_radius * (math.cos((angle * 2 * math.pi / 360)-(math.pi/2)))
local movey = txt_radius * (math.sin((angle * 2 * math.pi / 360)-(math.pi/2)))
cairo_select_font_face (display, "ubuntu", CAIRO_FONT_SLANT_NORMAL, txt_weight);
cairo_set_font_size (display, txt_size);
cairo_set_source_rgba (display, rgb_to_r_g_b(txt_fg_colour, txt_fg_alpha));
cairo_move_to (display, x + movex - (txt_size / 2), y + movey + 3);
cairo_show_text (display, value);
cairo_stroke (display);
end

-------------------------------------------------------------------------------
-- draw_gauge_ring
-- displays gauges
--
function draw_gauge_ring(display, data, value)
local max_value = data['max_value']
local x, y = data['x'], data['y']
local graph_radius = data['graph_radius']
local graph_thickness, graph_unit_thickness = data['graph_thickness'], data['graph_unit_thickness']
local graph_start_angle = data['graph_start_angle']
local graph_unit_angle = data['graph_unit_angle']
local graph_bg_colour, graph_bg_alpha = data['graph_bg_colour'], data['graph_bg_alpha']
local graph_fg_colour, graph_fg_alpha = data['graph_fg_colour'], data['graph_fg_alpha']
local hand_fg_colour, hand_fg_alpha = data['hand_fg_colour'], data['hand_fg_alpha']
local graph_end_angle = (max_value * graph_unit_angle) % 360

-- background ring
cairo_arc(display, x, y, graph_radius, angle_to_position(graph_start_angle, 0), angle_to_position(graph_start_angle, graph_end_angle))
cairo_set_source_rgba(display, rgb_to_r_g_b(graph_bg_colour, graph_bg_alpha))
cairo_set_line_width(display, graph_thickness)
cairo_stroke(display)

-- arc of value
local val = value % (max_value + 1)
local start_arc = 0
local stop_arc = 0
local i = 1
while i <= val do
start_arc = (graph_unit_angle * i) - graph_unit_thickness
stop_arc = (graph_unit_angle * i)
cairo_arc(display, x, y, graph_radius, angle_to_position(graph_start_angle, start_arc), angle_to_position(graph_start_angle, stop_arc))
cairo_set_source_rgba(display, rgb_to_r_g_b(graph_fg_colour, graph_fg_alpha))
cairo_stroke(display)
i = i + 1
end
local angle = start_arc

-- hand
start_arc = (graph_unit_angle * val) - (graph_unit_thickness * 2)
stop_arc = (graph_unit_angle * val)
cairo_arc(display, x, y, graph_radius, angle_to_position(graph_start_angle, start_arc), angle_to_position(graph_start_angle, stop_arc))
cairo_set_source_rgba(display, rgb_to_r_g_b(hand_fg_colour, hand_fg_alpha))
cairo_stroke(display)

-- graduations marks
local graduation_radius = data['graduation_radius']
local graduation_thickness, graduation_mark_thickness = data['graduation_thickness'], data['graduation_mark_thickness']
local graduation_unit_angle = data['graduation_unit_angle']
local graduation_fg_colour, graduation_fg_alpha = data['graduation_fg_colour'], data['graduation_fg_alpha']
if graduation_radius > 0 and graduation_thickness > 0 and graduation_unit_angle > 0 then
local nb_graduation = graph_end_angle / graduation_unit_angle
local i = 0
while i < nb_graduation do
cairo_set_line_width(display, graduation_thickness)
start_arc = (graduation_unit_angle * i) - (graduation_mark_thickness / 2)
stop_arc = (graduation_unit_angle * i) + (graduation_mark_thickness / 2)
cairo_arc(display, x, y, graduation_radius, angle_to_position(graph_start_angle, start_arc), angle_to_position(graph_start_angle, stop_arc))
cairo_set_source_rgba(display,rgb_to_r_g_b(graduation_fg_colour,graduation_fg_alpha))
cairo_stroke(display)
cairo_set_line_width(display, graph_thickness)
i = i + 1
end
end

-- text
local txt_radius = data['txt_radius']
local txt_weight, txt_size = data['txt_weight'], data['txt_size']
local txt_fg_colour, txt_fg_alpha = data['txt_fg_colour'], data['txt_fg_alpha']
local movex = txt_radius * math.cos(angle_to_position(graph_start_angle, angle))
local movey = txt_radius * math.sin(angle_to_position(graph_start_angle, angle))
cairo_select_font_face (display, "ubuntu", CAIRO_FONT_SLANT_NORMAL, txt_weight)
cairo_set_font_size (display, txt_size)
cairo_set_source_rgba (display, rgb_to_r_g_b(txt_fg_colour, txt_fg_alpha))
cairo_move_to (display, x + movex - (txt_size / 2), y + movey + 3)
cairo_show_text (display, value)
cairo_stroke (display)

-- caption
local caption = data['caption']
local caption_weight, caption_size = data['caption_weight'], data['caption_size']
local caption_fg_colour, caption_fg_alpha = data['caption_fg_colour'], data['caption_fg_alpha']
local tox = graph_radius * (math.cos((graph_start_angle * 2 * math.pi / 360)-(math.pi/2)))
local toy = graph_radius * (math.sin((graph_start_angle * 2 * math.pi / 360)-(math.pi/2)))
cairo_select_font_face (display, "ubuntu", CAIRO_FONT_SLANT_NORMAL, caption_weight);
cairo_set_font_size (display, caption_size)
cairo_set_source_rgba (display, rgb_to_r_g_b(caption_fg_colour, caption_fg_alpha))
cairo_move_to (display, x + tox + 5, y + toy + 1)
-- bad hack but not enough time !
if graph_start_angle < 105 then
cairo_move_to (display, x + tox - 30, y + toy + 1)
end
cairo_show_text (display, caption)
cairo_stroke (display)
end

-------------------------------------------------------------------------------
-- go_clock_rings
-- loads data and displays clock
--
function go_clock_rings(display)
local function load_clock_rings(display, data)
local str, value = '', 0
str = string.format('${%s %s}',data['name'], data['arg'])
str = conky_parse(str)
value = tonumber(str)
draw_clock_ring(display, data, value)
end

for i in pairs(clock_h) do
load_clock_rings(display, clock_h)
end
for i in pairs(clock_m) do
load_clock_rings(display, clock_m)
end
for i in pairs(clock_s) do
load_clock_rings(display, clock_s)
end
end

-------------------------------------------------------------------------------
-- go_gauge_rings
-- loads data and displays gauges
--
function go_gauge_rings(display)
local function load_gauge_rings(display, data)
local str, value = '', 0
str = string.format('${%s %s}',data['name'], data['arg'])
str = conky_parse(str)
value = tonumber(str)
draw_gauge_ring(display, data, value)
end

for i in pairs(gauge) do
load_gauge_rings(display, gauge)
end
end

-------------------------------------------------------------------------------
-- MAIN
function conky_main()
if conky_window == nil then
return
end

local cs = cairo_xlib_surface_create(conky_window.display, conky_window.drawable, conky_window.visual, conky_window.width, conky_window.height)
local display = cairo_create(cs)

local updates = conky_parse('${updates}')
update_num = tonumber(updates)

if update_num > 5 then
go_clock_rings(display)
go_gauge_rings(display)
end

cairo_surface_destroy(cs)
cairo_destroy(display)
end
[/code]

# Use Xft?
use_xft yes
xftfont DejaVu Sans:size=8
xftalpha 0.8
text_buffer_size 2048

# Update interval in seconds
update_interval 1

# This is the number of times Conky will update before quitting.
# Set to zero to run forever.
total_run_times 0

# Create own window instead of using desktop (required in nautilus)
own_window yes
own_window_transparent yes
own_window_type override
own_window_class conky
own_window_hints undecorated,below,sticky,skip_taskbar,skip_pager
background no

# Use double buffering (reduces flicker, may not work for everyone)
double_buffer yes

# Minimum size of text area
minimum_size 180 0
#maximum_width 200

# Draw shades?
draw_shades no

# Draw outlines?
draw_outline no

# Draw borders around text
draw_borders no

# Stippled borders?
stippled_borders 0

# border margins
border_inner_margin 5

# border width
border_width 1

# Default colors and also border colors
default_color black
default_shade_color black
default_outline_color black
own_window_colour black
color1 black

# Text alignment, other possible values are commented
#alignment top_left
alignment top_right
#alignment bottom_left
#alignment bottom_right

# Gap between borders of screen and text
# same thing as passing -x at command line
gap_x 35
gap_y 10

# Subtract file system buffers from used memory?
no_buffers yes

# set to yes if you want all text to be in uppercase
uppercase no

# number of cpu samples to average
# set to 1 to disable averaging
cpu_avg_samples 2

# number of net samples to average
# set to 1 to disable averaging
net_avg_samples 2

# Force UTF8? note that UTF8 support required XFT
override_utf8_locale yes

# Add spaces to keep things from moving about? This only affects certain objects.
use_spacer none

TEXT
${font :style=Bold}SYSTEM${font} ${hr 2}
${font StyleBats:size=16}${font} ${alignc}Uptime: ${uptime}
${voffset 2}${font StyleBats:size=16}i${font} Kernel: ${alignr}${kernel}
${font Webdings:size=16}a${font} CPU1: ${cpu cpu1}% ${alignr}${cpubar cpu1 8,60}
${font Webdings:size=16}a${font} CPU2: ${cpu cpu2}% ${alignr}${cpubar cpu2 8,60}
${font Webdings:size=16}a${font} RAM: $memperc% ${alignr}${membar 8,60}
${font Webdings:size=16}a${font} RAM: Used ${alignr}$mem / $memmax
${font Webdings:size=16}a${font} SWAP: $swapperc% ${alignr}${swapbar 8,60}
${font Webdings:size=16}~${font} Battery: ${battery_percent BAT0}% ${alignr}${battery}

${font Webdings:size=16}·${font} ${alignc}HDD: ${execi 2 /usr/sbin/hddtemp /dev/sda -q | awk '{print $3; }' | cut -c 1-2}°С HDD1: ${execi 2 /usr/sbin/hddtemp /dev/sdb -q | awk '{print $3; }' | cut -c 1-2}°С CPU: ${execi 5 cat /sys/devices/virtual/hwmon/hwmon0/temp1_input | cut -c 1-2}°C

${font :style=Bold}HDD${font} ${hr 2}
${voffset 4}${font Pie charts for maps:size=14}${font} ${voffset -5}Root:
${voffset 4}${fs_used /}/${fs_size /} ${alignr}${fs_bar 8,60 /} ${fs_free_perc /}%
${voffset 4}${font Pie charts for maps:size=14}${font} ${voffset -5}Home:
${voffset 4}${fs_used /home}/${fs_size /home} ${alignr}${fs_bar 8,60 /home} ${fs_free_perc /home}%
${font Pie charts for maps:size=14}${font} ${voffset -5}Media:
${voffset 4}${fs_used /media/Media}/${fs_size /media/Media} ${alignr}${fs_bar 8,60 /media/Media} ${fs_free_perc /media/Media}%
${font Pie charts for maps:size=14}${font} ${voffset -5}Media1:
${voffset 4}${fs_used /media/Media1}/${fs_size /media/Media1} ${alignr}${fs_bar 8,60 /media/Media1} ${fs_free_perc /media/Media1}%

${font :style=Bold}NET${font} ${hr 2}
${voffset 4}${font Webdings:size=14}”${font} Up: ${upspeed wlan1} ${alignr}${upspeedgraph wlan1 8,60 000000 000000}
${voffset 4}${font Webdings:size=14}“${font} Down: ${downspeed wlan1} ${alignr}${downspeedgraph wlan1 8,60 000000 000000}
${voffset 4}${font Webdings:size=14}¬${font} Lan Ip: ${alignr}${addr eth0}
${voffset 4}${font Webdings:size=14}¬${font} WLan Ip: ${alignr}${addr wlan1}
${font Webdings:size=16}a${font} Signal:${alignr}${wireless_link_qual wlan1}%
${font Webdings:size=16}a${font} Speed:${alignr}${wireless_bitrate wlan1}
#${font Webdings:size=16}a${font} AP Name:${alignr}${wireless_essid wlan1}
${font Webdings:size=16}a${font} Mode:${alignr}${wireless_mode wlan1}
${font :style=Bold}PROCESSES${font} ${hr 2}
NAME $alignr PID CPU
${color red}${top name 1} $alignr ${top pid 1} ${top cpu 1}
${color}${top name 2} $alignr ${top pid 2} ${top cpu 2}
${top name 3} $alignr ${top pid 3} ${top cpu 3}
${top name 4} $alignr ${top pid 4} ${top cpu 4}
${top name 5} $alignr ${top pid 5} ${top cpu 5}
${hr 1}
NAME $alignr PID MEM
${color red}${top_mem name 1}$alignr ${top_mem pid 1} ${top_mem mem 1}
${color}${top_mem name 2}$alignr ${top_mem mem 2}
${top_mem name 3}$alignr ${top_mem mem 3}
${top_mem name 4}$alignr ${top_mem mem 4}
${hr 1}
NAME $alignr PID HDD
${color red}${top_io name 1} $alignr ${top_io pid 1}
${color}${top_io name 2} $alignr ${top_io pid 2}
${top_io name 3} $alignr ${top_io pid 3}

# .conkyrc - Edited from various examples compiled from the Web
# by Xplosive
# by Neonboy

# --- Window Layout & Options --- #
background no
own_window yes
own_window_colour brown
own_window_transparent yes
own_window_type override
own_window_transparent yes
own_window_hints undecorated,below,sticky,skip_taskbar,skip_pager
double_buffer yes
use_spacer right
use_xft yes
alignment top_right
gap_x 15
gap_y 22

# --- Colours, Sizes, Fonts & Margins --- #
update_interval 2
maximum_width 230
stippled_borders 3
border_margin 9
border_width 10
default_color white
no_buffers yes

# --- Text --- #
draw_outline no
draw_borders no
font Sans:size=8:weight=bold
uppercase no
draw_shades yes
override_utf8_locale yes

TEXT
${font Sans:size=13:weight=bold}${color cyan}${alignc}${time %H:%M}
${font Sans:size=10:weight=bold}${color cyan}${alignc}${time %A} / ${time %e} / ${time %B} #/ ${time %G}

${font Sans:size=9:weight=bold}${color orange}Инф. о системе:${alignr}$color Linux Mint 14${hr 2}$color${font Sans:size=8:weight=bold}
${color orange}Версия ядра:$color ${alignr}$kernel${alignr}
${color orange}Арх.:$color ${alignr}$machine
${color orange}Компьютер:$color ${alignr}MSI-K9N
${color orange}Работает:$color ${alignr} $uptime
${font Sans:size=8:weight=bold}${color orange}Версия Conky: ${color}${alignr}${conky_version}
${font Sans:size=9:weight=bold}${color orange}Процессор:${hr 2}
${font Arial:bold:size=8}${color #ff0000}${execi 99999 cat /proc/cpuinfo | grep "model name" -m1 | cut -d":" -f2 | cut -d" " -f2- | sed 's#Processor ##'}$font$color
${color orange}Частота: ${alignr}${color cyan}${freq_g 2}ГГц
${font Sans:size=9:weight=bold}${color orange}Температура по ядрам:${hr 2}
${font Sans:size=8:weight=bold}${color orange}Ядро№ 1 :${alignr}${color cyan}${execi 1 sensors |grep "Core0 Temp" | cut -c 16-22}
${color orange}Ядро№ 2 :${alignr}${color cyan}${execi 1 sensors |grep "Core1 Temp" | cut -c 16-22}
${font Sans:size=9:weight=bold}${color orange}Загрузка CPU:${color cyan} ${cpu cpu0}% ${alignr}${color red} ${cpubar 9,96}

${color orange} Ядро№ 1 Ядро№ 2
${color cyan} ${cpu cpu1}% ${color orange}${color cyan} ${cpu cpu2}%
$color${cpugraph cpu1 45,105 000000 A7A7A7} ${cpugraph cpu2 45,105 000000 A7A7A7}
${font}${color orange}CPU-Куллер: ${color cyan}${alignr}${font}${hwmon fan 2} RPM
${font}${color orange}Sys-Куллер: ${color cyan}${alignr}${font}${hwmon fan 1} RPM
#${font Sans:size=9:weight=bold}${color orange}Температура Nvidia GPU:${alignr}${color cyan}+${nvidia temp}°С
${font}${color orange}ST3250310AS:${color cyan}${alignr}${font}${hddtemp /dev/sda}°C
${font}${color orange}AMD Radeon HD 6670:${color cyan}${alignr}${font}${execi 4 aticonfig --adapter=0 --odgt | grep -i Temp | cut -c37-42}°С
${font}${color orange}GPU load:${color cyan}${alignr}${font}${execi 1 aticonfig --adapter=0 --odgc | grep -i GPU | cut -c31-34}

${font Sans:size=9:weight=bold}${color orange}TOP 5 Процессов (Загрузка ЦП) ${hr 2}$color ${font Sans:size=8:weight=bold}${color #ff0000}
Название ${alignr}ID ${alignr}ЦП $color
1. ${top name 1} ${alignr}${top pid 1} ${alignr}${top cpu 1}
2. ${top name 2} ${alignr}${top pid 2} ${alignr}${top cpu 2}
3. ${top name 3} ${alignr}${top pid 3} ${alignr}${top cpu 3}
4. ${top name 4} ${alignr}${top pid 4} ${alignr}${top cpu 4}
5. ${top name 5} ${alignr}${top pid 5} ${alignr}${top cpu 5}

${font Sans:size=9:weight=bold}${color orange}TOP 5 Процессов (Загрузка ОЗУ) ${hr 2}$color${font Sans:size=8:weight=bold}${color #ff0000}
Название ${alignr}ID ${alignr}ОЗУ $color
1. ${top_mem name 1} ${alignr}${top_mem pid 1} ${alignr}${top_mem mem 1}
2. ${top_mem name 2} ${alignr}${top_mem pid 2} ${alignr}${top_mem mem 2}
3. ${top_mem name 3} ${alignr}${top_mem pid 3} ${alignr}${top_mem mem 3}
4. ${top_mem name 4} ${alignr}${top_mem pid 4} ${alignr}${top_mem mem 4}
5. ${top_mem name 5} ${alignr}${top_mem pid 5} ${alignr}${top_mem mem 5}

${font Sans:size=9:weight=bold}${color orange}ОЗУ и SWAP ${hr 2}$color${font Sans:size=8:weight=bold}
${color white}ОЗУ$color ${memperc}% ${color #ff6600}${membar 6.180}
${color white}SWAP$color ${swapperc}% ${color #ff6600}${swapbar 6.180}

${font Sans:size=9:weight=bold}${color orange}Свободное пространство на HDD${hr 2}$color${font Sans:size=8:weight=bold}

${color red}Root$color ${fs_free_perc /}%$alignr${fs_free /}/ ${fs_size /}
${color #ff6600}${fs_bar 10 /}
#${color red}Home$color ${fs_free_perc /home}%$alignr${fs_free /home}/ ${fs_size /home}
#${color #ff6600}${fs_bar 6 /home}

${font Sans:size=9:weight=bold}${color orange}Сеть (IP: ${addr eth0}) ${hr 2}$color${font Sans:size=8:weight=bold}
${color orange}Скорость передачи данных$color
${font Sans:size=7:weight=bold}${color red} Down.$color ${downspeed eth0}Кб/с${alignr}${color red}Up.$color${alignr} ${upspeed eth0}Кб/с
${downspeedgraph eth0 30,105 000000 00ff00} ${alignr}${upspeedgraph eth0 30,105 000000 ff0000}$color

${font Sans:size=9:weight=bold}${color orange}Трафик ${hr 2}$color${font Sans:size=8:weight=bold}
${color white}Входящ. ${totaldown eth0} ${alignr}${color white}Исходящ.${alignr} ${totalup eth0}
